Function Description:
Element measurement: Measuring points, lines, circles, arcs, angles, oval, rectangle measuring a
predetermined number of points, automatic identification points, lines, circles, arcs.
Element structure: Center construction, the intersection of structure, the midpoint structure, line structure,
round structure, angle configuration.
Preset elements: points, lines, circles, arcs. Coordinate translation, straighten the workpiece. Straighten any
axis coordinate system reset.
Graphics: Graphics zoom, graphics narrowing, graphics pan, graphics selected, select the circle, delete the
graphic, graphic print. Zoom settings, set the image gray, saturation, contrast, save, images in BMP format.
A variety of edge finder mode, the computer automatically take points, automatic identification round, arc greatly
improve mining point speed.
Image support S-Video, AV terminal, USB terminal input; image size of 640 * 480mm. Measurement data directly
into AutoCAD for statistical analysis, can draw simple Xbar-s control chart obtained various parameters Ca.
Multilingual interface switching.
