2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
  • 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
  • 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
  • 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
  • 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
  • 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
  • 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
  • 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing
  • 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing

2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing

Product Details:
Place of Origin: Guangdong, China
Brand Name: WM-3D
Certification: iso9001
Model Number: VMT-4030
Detail Information
Place of Origin:
Guangdong, China
Brand Name:
WM-3D
Certification:
iso9001
Model Number:
VMT-4030
Warranty:
1 Year, 12months
Customized Support:
OEM, ODM
Name:
Cheapest Toolmaker Measuring Microscope
Material:
Granite
Usage:
Inspection
Weight:
260kg
Color:
White
Port:
Shenzhen
Highlight:

High Light

Highlight:

2000X Video Measuring Microscope

,

Industrial Video Measuring Microscope

Trading Information
Price:
$7,000.00/sets 1-4 sets
Packaging Details:
Optical microscope camera mobile repair microscope digital microscope Used in industrial testing medicine etc. 2000X
Vacuum packing & Free fumigation wooden case
Wooden case size: 850*600*1200mm
Product Description
2000X Video Measuring Microscope For Industrial Medicine Testing
Optical microscope camera mobile repair microscope digital microscope used in industrial testing, medicine, and related applications with 2000X magnification capability.
2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing 0 2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing 1
Key Features
  • Bright-field view investigation with WM-3D positive imaging for clear, wide-market pictures
  • Powerful WM-3D software for comprehensive measurement and analysis capabilities
  • Long working distance lens with magnification up to 2800X
  • Precision screw-driven positioning for enhanced accuracy
  • Large-size measurement capability with fast-moving loading platform
  • Z-axis hand wheel with large coarse tuning for precise workpiece focusing
  • X and Y axes with built-in zero switching functionality
  • Video device compatibility for system upgrade to video measurement
  • Natural aging treated table with Taiwan LB components for long-term precision
2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing 2
Technical Specifications
MODEL VMT-4030
Working Travel (X*Y*Z axis) 400*300*200mm
Dimension (mm) 700x900*1150 (L*W*H)
Deviation (3+L/200)μm, where L is measurement length in mm
Resolution 1μm
Image Processor SONY 1/3" color CCD camera
Eyepiece PL 10X/Ø22mm
Objective Standard: LMPlan 5X,10X,20X DIC
Optional: PL L 5X,10X,20X,50X,100X
Nosepiece Inclined quintuple nosepiece for bright field with DIC slot
Max. Magnification 2800x (Objective*1/3'' CCD)
Max. Workload 35kg
Max. Working Height 200mm
G.W. 260kg
Power Supply AC110V/60Hz; 220V/50Hz
Optional Accessories Powerful Measuring Software WM-3D
DC-3000 Data Terminal
Granite Work Desk
PC & 19" LCD Monitor
Warranty & Services
2000X Video Measuring Microscope with Granite Material and 2800X Max Magnification for Industrial Medicine Testing 3
12 months warranty. Buy with confidence!
  • 12 months from date of assembly and acceptance, not exceeding 15 months from shipment date
  • Comprehensive phone and internet teaching with combined after-sales advisory service
  • Lifetime warranty services for machine users (cost-based)
  • Machine failures caused by our side: return spare parts to us at our cost
  • On-site technician services: technical service free (excluding travel and accommodation)
  • Extended warranty period with lifetime after-sales advisory service
  • Cost-based spare parts availability for users
  • Lifetime value-added technical services at preferential prices
