CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range

CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range
CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range
CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range

Large Image :  CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range

Product Details:
Place of Origin: Guangdong, China
Brand Name: WM-3D
Certification: ISO9001
Model Number: CNC-8010D
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $30,000.00/sets
Packaging Details: Gantry CNC Video Measuring Machine With Measuring range 800*1000mm Wooden Cases
Delivery Time: 7days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100sets/21days

CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range

Description
Warranty: 1 Year Customized Support: OEM, ODM
Product Name: Gantry CNC Video Measuring Machine With Measuring Range 800*1000mm Model: CNC-8010D
Color: White General Use: Electronices ,plastics,mold,machinery,hardware,clocks,mobile
Material: Granite Usage: Measuring
Weight: 1200KG Type: Fully Automatic
Usage: Optical System Power: AC220V 50HZ 750W
High Light:

Video Gantry Coordinate Measuring Machine

,

CNC Gantry Coordinate Measuring Machine

,

1000mm video coordinate measuring machine

Gantry CNC Video Measuring Machine With Measuring range 800*1000mm

Products Description
CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range 0
Items
CNC-8010D
CNC-1015D
CNC-1216D
Dimension(mm)(L×W×H)
1400*1600*1650
1600*2400*1650
2000*2400*1650
Measuring range(mm)(X×Y×Z)
800*1000*200
1000*1600*200
1200*1600*200
Measuring Accuracy(μm
≦3+L/200
3+L/200
3+L/200
Repeatability (μm)
3
3
3
Weight(kg)
1200
1700
2000
Image and Measuring
CCD
Japanese SOnYCcD

Len
High definition zoomlens/Continuous magnification 0.7-5.0x

Magnification
40-230X( For reference only. With different camera and lens the magnification will be different. )

ptical scale resolution
x/Y/z axis o.0002mm ( 0.2um )

Working distance
108mm
Measurement software
Combine the 3D measurement software developed by the imported software function to improve the boundary resolution.
Driving system
X/Y/Z three-axis high performance Taiwan servo motor, double closed loop control system
Illumination
Program-controlled five-ring eight-zone surface light source,LED contour light source, coaxial light source.Different colors are
added to different products.
CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range 1
Our Advantages
High-precision fully automatic measurement, CNC four-axis control.
High-precision and high-strength machine: 00-class marble base/column/workbench with high precision and good stability
XYZ three-axis imported precision linear guide / imported grinding grade ball screw drive system, long life and good stability.0.2um.High precision metal patch ruler o.2um.
The Wm0750 automatic zoom opticallens enables fully automatic measurement without the need for zoom correction. HD SONY CcD camera with high quality measurement screen Autofocus measurement, optical altimetry flatness, UK RENISHAW contact probe, Program-controlled five-ring eight-zone surace light souceLED contour light source, coaxial light source.Different colors are added to different products. It is equipped with a joystick for easy operation at any position. The navigation CCD camera indicates the measurement position, which is quick to locate and convenient for measurement. Combine the 3D measurement software developed by the imported software function to improve the boundary resolution.
Our Services

After-sales service commitment

Wangmin Optical Instrument



PURCHASE AND CONSULTING

From the right selection to sample test, from the installation site to installation site survey to the fixture system configuration,experienced sales and service engineers, through all over the country sales and service center,correct selection provides guidance for the customer.



SERVICE AND RETROFIT

Our measuring machine maintenance specialists,can provide maintenance regularly for measuring system,adjustment and calibration,determine the system always work in the best condition,and try to eliminate the faults in the bud,thereby reducing maintenance costs,prolong the service life of measurement system significantly.



TRANSFORMATION AND UPGRADING

Keep your measurement system is always the most optimal technical condition, through the control system,measurement software,completely upgraded probe system and transmission system,the technology of measuring machine increase greatly.



INSTALLATION AND WARRANTY

Nationwide sales and service center,by the method of the standard process,to provide customers with timely and fast installation and acceptance of machine, product warranty services,training and equipment use problems,4 hour telephone

response processing,8 hours door-to-door service, to solve customer's worries.



INSTALLATION AND WARRANTY

We have to training covers every aspect of customer needs,ranging from primary operation training to the professional training of senior training phase,and can be made according to customer needs to provide special training.

To provide up to five:

The door one-on-one training, to learn is to,to sign for training qualified list Paper release notes,detailed machine use,the software function is introduced Random distribution teaching CD,installation CD,watch directly,more specific and convenient

The company network teaching video,direct knowledge,convenient measurement Multimedia remote teaching,quickly resolve customer problems

Company Information
CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range 2
CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range 3
Packaging & Shipping
CNC Video Gantry Coordinate Measuring Machine 800×1000mm Range 4
FAQ
Q1: What kind of equipment do you mainly produce?
A: Hello! Our main production equipment are: automatic image measuring instrument,manual image measuring instrument,large gantryimage measuring instrument,one key measuring instrument. Automatic vision screening equipment, non-standard vision detection equipment, etc.

Q2: Do you accept custom service? Can l print my logo on the machine?
A: Yes, all of our products can be customized , if you have a logo requirement,we can also customize for you.

Q3: why do you choose us?
A: 1.We have focused on the measurement of products for more than 10years, with a professional R & Dteam and after-sales team.
A2.It is located in Dongguan City, a world-famous manufacturing city.
A3: after-sales service for 12 months, simple problems within 48 hours todeal with timely.

Q4: what is your delivery time? what about the packing?
A: Our delivery time is 5 working days after receiving the deposit or order confirmation,and 10-20 working days for customized machines.Our packaging is wrappedand fixedwith professional machine packaging film inside, and woodenbox packaging and screwfixing are used on the outside.Ensure that theproduct arrives safely without damage.

Q5:Is on-site training available?
A: can, the need for on-site training needs to confirm the specific time with

Q6:What are the payment terms?
A:T/T,L/C, western Union, etc.

Q7.wWhat are your payment terms?
A: T/T 30% as a deposit,70% before delivery.Before you pay the balance, we will showyou the photos ofthe product and packaging. or 100% LC at sight.

Q8:Can we test samples before placing an order?
A: Of course, we can test samples for free and provide you with a test report.lf you have any difficulties, please contact our business manager
