Home > Products >
Contour Measuring Machine
>
High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement
  • High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement
  • High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement
  • High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement
  • High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement
  • High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement
  • High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement
  • High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement
  • High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement

High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement

Product Details:
Place of Origin: Guangdong, China
Brand Name: WM-3D
Certification: ISO9001
Model Number: CNC-4030AH
Detail Information
Place of Origin:
Guangdong, China
Brand Name:
WM-3D
Certification:
ISO9001
Model Number:
CNC-4030AH
Warranty:
1 Year
Customized Support:
OEM, ODM
Product Name:
High Precision Efficiency Metrology Equipment Image Cnc Optical Video Measuring Machine
Model:
CNC-4030AH
Color:
White
General Use:
Electronices ,plastics,mold,machinery,hardware,clocks,mobile
Material:
Granite
Usage:
Measuring
Weight:
350KG
Power Supply:
AC 220V/50-60Hz
Type:
Fully Automatic
Usage:
Optical System
Highlight:

High Light

Highlight:

Precision Optical Metrology System

,

CNC Optical Metrology System

,

Optical optical metrology equipment

Trading Information
Minimum Order Quantity:
1
Price:
$14,000.00/sets
Packaging Details:
High Precision Efficiency Metrology Equipment Image cnc optical video measuring machine Wooden Cases
Delivery Time:
2days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Product Description
High Precision Optical Metrology System Equipment For Image CNC Optical Video Measuring
High Precision Efficiency Metrology Equipment Image CNC optical video measuring machine delivers exceptional accuracy and performance for industrial measurement applications.
High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 0
Technical Specifications
Items CNC-3020AH CNC-4030AH CNC-5040AH
Dimension (mm) (L×W×H) 700×850×1650 800×900×1650 900×1050×1650
Measuring range (mm) (X×Y×Z) 300×200×200 400×300×200 500×400×200
Measuring Accuracy (μm) 3+L/200 3+L/200 3+L/200
Repeatability (μm) 3 3 3
Weight (kg) 300 380 450
Image and Measuring System
CCD: Japanese SONY CCD
Lens: High definition zoom lens/Continuous magnification 0.7-5.0x
Magnification: 40-230X (Reference only. Varies with camera and lens configuration)
Optical Scale Resolution: X/Y/Z axis 0.0002mm (0.2μm)
Working Distance: 108mm
Measurement Software
Combines 3D measurement software developed with imported software functionality to enhance boundary resolution.
Driving System
X/Y/Z three-axis high performance Taiwan servo motor with double closed loop control system.
Illumination System
Program-controlled five-ring eight-zone surface light source, LED contour light source, coaxial light source. Different colors are added to different products.
High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 1
Our Advantages
  • High-precision fully automatic measurement with CNC four-axis control
  • High-precision and high-strength machine: 00-class marble base/column/workbench with excellent stability
  • XYZ three-axis imported precision linear guide / imported grinding grade ball screw drive system for long life and stability
  • High precision metal patch ruler 0.2μm
  • WM0750 automatic zoom optical lens enables fully automatic measurement without zoom correction
  • HD SONY CCD camera with high quality measurement screen
  • Autofocus measurement, optical altimetry flatness
  • UK RENISHAW contact probe
  • Program-controlled five-ring eight-zone surface light source, LED contour light source, coaxial light source
  • Equipped with joystick for easy operation at any position
  • Navigation CCD camera indicates measurement position for quick location and convenient measurement
  • 3D measurement software combines imported software functionality to improve boundary resolution
High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 2 High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 3
Our Services
High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 4
  • 12-month warranty from time of receipt
  • Phone and internet teaching with comprehensive after-sale advisory service
  • Life warranty services for machine (cost-based)
  • Machine failure caused by our side: return spare parts with cost covered by us
  • Technician visits for training and technical service are free (excluding travel and accommodation)
  • Extended warranty period with lifelong after-sale advisory service
  • Spare parts available for users at cost
  • After-sales value added technical service provided at preferential prices for life
Company Information
High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 5 High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 6
Packaging & Shipping
High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 7
Frequently Asked Questions
High Precision Fully Automatic CNC Measuring System with Granite Base for Optical Video Measurement 8
Q1: What kind of equipment do you mainly produce?
Hello! Our main production equipment includes: automatic image measuring instrument, manual image measuring instrument, large gantry image measuring instrument, one key measuring instrument, automatic vision screening equipment, and non-standard vision detection equipment.
Q2: Do you accept custom service? Can I print my logo on the machine?
Yes, all of our products can be customized. If you have logo requirements, we can also customize for you.
Q3: Why do you choose us?
  • Over 10 years of focused experience in product measurement with professional R&D and after-sales teams
  • Located in Dongguan City, a world-famous manufacturing hub
  • 12-month after-sales service with simple problems resolved within 48 hours
Q4: What is your delivery time? What about the packing?
Our delivery time is 5 working days after receiving deposit or order confirmation (10-20 working days for customized machines). Our packaging includes professional machine packaging film internally, with wooden box packaging and screw fixing externally to ensure safe arrival without damage.
