Customized Small OMM Optical Measurement Machine with 3um Accuracy for Electronic Products

Name: Customized Small OMM Optical Measurement Machine with 3um Accuracy for Electronic Products
Brand: Dongguan Wang Min Optical Instrument Co., Ltd.
SKU: VMS-2010F
Price: 1.00 USD
Availability: InStock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	WM-3D
Certification:	ISO9001 CE
Model Number:	VMS-2010F

Detail Information

Place of Origin:

Guangdong, China

Brand Name:

WM-3D

Certification:

ISO9001 CE

Model Number:

VMS-2010F

Warranty:

12 Months, One Year

Customized Support:

OEM, ODM, OBM

Power:

Electronic

Name:

WM-3D Measurement Digital Video Measuring Systems CMM VMS-2010F

Accuracy:

3um

General Use:

Electrics,plastics,mold,machinery,connectors And Mobile

Function:

Measuring And Detect

Weight:

180KG

Velocity:

Hand Control

Color:

White

Product Name:

WM-3D Measurement Digital Video Measuring Systems CMM VMS-2010F

Type:

VMS-2010F

Highlight:

High Light

Highlight:

Small OMM Optical Measurement Machine

Customized OMM Optical Measurement Machine

Electronic omm machine

Trading Information

Minimum Order Quantity:

Price:

$2,500.00/sets 1-1 sets

Packaging Details:

Small electronic product measuring instrument wooden cases

Delivery Time:

2days

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Product Description

Customized Small OMM Optical Measurement Machine For Electronic Products

Small Electronic Product Measuring Instrument

Technical Specifications

Items	VMS-2010F	VMS-3020-F	VMS-4030F	VMS-5040F
Dimension (mm) (L×W×H)	500×700×1100	600×750×1100	700×900×1150	850×1050×1200
Measuring Range (mm) (X×Y×Z)	200×100×200	300×200×200	400×300×200	500×400×200
Measuring Accuracy (μm)	3+L/200	3+L/200	3+L/200	3+L/200
Repeatability (μm)	3	3	3	3
Weight (kg)	150	180	200	240

Image and Measuring System

CCD: Japanese Sony CCD
Lens: WM HD zoom lens / continuous magnification 0.7-4.5x
Magnification: 30-210X
Optical Scale Resolution: X/Y/Z axis 0.0005mm (0.5μm)
Measuring Range: 9.0mm-1.35mm

Advanced Measurement Capabilities

Measuring System: Auxiliary focusing measurement, optical measuring altitude and flatness, and can be equipped with the British RENISHAW contact probe.
Driving System: Versatile data processor can measure points, lines, loops, circles, angles, etc.
Illumination: Surface light and projection light, cold light, long life, brightness adjustable

Our Advantages

WM Continuous zoom optical lens, different frames, different magnification, without zoom correction
HD Japanese Sony CCD camera, high quality measuring screen
Auxiliary focusing measurement, optical measuring altitude and flatness, and can be equipped with the British RENISHAW contact probe
Surface light, LED profile light, coaxial light - choose match programmable three ring eight area light
Laser pointer indicates the position of measuring, rapid positioning and convenient measurement
Can match foot switch, easy to operate at any place
Small WM-CNC-3020/WM-CNC-4030 designed for rapid measurement of small products
Measuring speed up to 200mm-400mm/s, batch measurement is quick
Auto determine OK or NG, greatly reduce human error, improve work efficiency
10-20 times faster than ordinary manual machines

Our Services

Company Information

Certifications

1. Our software through the national professional organization of standard measurement certification.
2. Our machines can give HSR agency of standard measurement certification.

Packaging & Shipping

Frequently Asked Questions

Q: Do you accept custom service? Can I print my logo on the machine?

A: Yes, all of our products can be customized. If you have a logo requirement, we can also customize for you.

Q: Why do you choose us?

A1: We have focused on the measurement of products for more than 10 years, with a professional R&D team and after-sales team.
A2: Located in Dongguan City, a world-famous manufacturing city.
A3: After-sales service for 12 months, simple problems within 48 hours to deal with timely.

Q: What is your delivery time? What about the packing?

A: Our delivery time is 5 working days after receiving the deposit or order confirmation, and 10-20 working days for customized machines. Our packaging is wrapped and fixed with professional machine packaging film inside, and wooden box packaging and screw fixing are used on the outside. Ensure that the product arrives safely without damage.
