Description
Warranty: 1 Year Customized Support: OEM, ODM
Name: 3um Accuracy Manual Optical Lens Machine, Vision Measuring System Accuracy: 3um
Velocity: Hand Control Function: Measuring And Detect
General Use: Electrics,plastics,mold,machinery,connectors And Mobile Color: White
Power: 220V /50HZ Product Name: 3um Accuracy Manual Optical Lens Machine, Vision Measuring System
High Light:

3um Vision Measurement System

,

Vision Measurement System Manual

,

Electronics vision measuring machine

3um accuracy manual optical lens machine, vision measuring system

Product Description

3um Accuracy Vision Measurement System Machine Manual For Electronics 0

1. Zaxis auto focus Video Measuring Machine can measure point, line, circle, arc and oval,rectangular with the multipoint positioning function, combination of measurements,center structure and the intersection of structure, the midpoint of construction, line structure,a round structure.

2. It has various functions of data processing, display, input and output, Measurement data output Word,Excel and Auto CAD directly to conduct statistical analysis, particularly, and the work piece straightening function is very useful.

3. Digital measurement and data processing system are made up by the two coordinate's studio,the optical grating and the SDK -3000 data card.

4. It has RS232 interface with a computer and specialized measurement software which can also processes and output circular mapping.

5. Z axis motorized, it can realize auto focus. make the image to be the clearest situation.
3um Accuracy Vision Measurement System Machine Manual For Electronics 1
Functions



3um Accuracy Vision Measurement System Machine Manual For Electronics 2
3um Accuracy Vision Measurement System Machine Manual For Electronics 3Mainly for metallograhpic measurement & analysis!These "Universal" models combine a measuring stand with the best of metallurgical microscope components for high resolution imaging and critical measurements. Featuring the full range of advanced infinity objectives and microscopy techniques including: brightfield,darkfield, DIC contrast, polarizing and epifluorescence.Up to five objectives may bemounted on the nosepiece.With more usages if upgraded.
Specifications

Model

WM-2010F

WM-3020F

WM-4030F

WM-5040F

Worktable

Metal table’s size(mm)

350*220

450*350

550*450

700*600

Glass table’s size(mm)

230*130

330*230

430*330

530*430

Three axis travel Travel(mm)

200*100

300*200

400*300

500*400

Weight(kg)

170

260

300

500

Dimension(L)*(W)*(H)

  500*700*1100

600*750*1100

700*900*1150

850*1050*1200

Measuring System

(Standard Accessories)

Camera :SONY1 / 3" Color CCD Camera

Lens magnification :0.7~4.5X       WD:95mm

Total magnification:30~230X        Object view:7~1.1mm

Double Cross Line Generator

Data Resolution:0.001mm

Z-axis lifting travel (mm):150mm (AUTO FOCUS)

The indication error of X,Y-axis ≤(3+L/200)µm (L be regarded as measured length, units: mm)

Lighting: Surface light and transmission light are used LED, brightness adjustable  Power:220/110V(AC),50HZ 30W
