Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement
  • Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement
  • Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement
  • Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement
  • Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement
  • Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement
  • Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement
  • Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement
  • Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement

Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement

Product Details:
Place of Origin: Guangdong, China
Brand Name: WangMin Optical
Certification: iso9001
Model Number: VMS-2010
Detail Information
Place of Origin:
Guangdong, China
Brand Name:
WangMin Optical
Certification:
iso9001
Model Number:
VMS-2010
Warranty:
1 Year, 12months
Customized Support:
OEM, ODM
Name:
Factory Supplier Provide Image Measuring Instrument With Good Price
Accuracy:
3um
Velocity:
Hand Control
Function:
Measuring And Detect
General Use:
Electrics,plastics,mold,machinery,connectors And Mobile
Color:
White
Power:
220V /50HZ
Highlight:

High Light

Highlight:

Manual 2D Coordinate Measuring Machine

,

2D Coordinate Measuring Machine 3um

,

220V manual coordinate measuring machine

Trading Information
Price:
$4,100.00/sets 1-4 sets
Packaging Details:
Factory Supplier Provide Image Measuring Instrument With Good Price
Export wooden box packaging
Factory Price!!optical Metal Image Measuring Machine
wooden case:950*850*1390MM
Product Description
Manual 2D Coordinate Measuring Machine
High-precision 3μm accuracy measurement system operating at 220V 50HZ
Product Overview
Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 0
Key Features
  • Z-axis auto focus Video Measuring Machine capable of measuring points, lines, circles, arcs, ovals, and rectangles
  • Multipoint positioning function with combination measurements, center structure, intersection structure, midpoint construction, line structure, and round structure
  • Comprehensive data processing with display, input and output functions
  • Measurement data export to Word, Excel, and AutoCAD for statistical analysis
  • Advanced workpiece straightening function
  • Digital measurement system with coordinate studio, optical grating, and SDK-3000 data card
  • RS232 computer interface with specialized measurement software for circular mapping
  • Motorized Z-axis for automatic focus optimization
Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 1
Advanced Functions
Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 2 Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 3
Primarily designed for metallographic measurement and analysis, these universal models combine a measuring stand with premium metallurgical microscope components for high-resolution imaging and critical measurements. Features include advanced infinity objectives and microscopy techniques: brightfield, darkfield, DIC contrast, polarizing, and epifluorescence. Accommodates up to five objectives on the nosepiece with additional usage capabilities through upgrades.
Technical Specifications
Model WM-2010F WM-3020F WM-4030F WM-5040F
Metal Table Size (mm) 350×220 450×350 550×450 700×600
Glass Table Size (mm) 230×130 330×230 430×330 530×430
Three Axis Travel (mm) 200×100 300×200 400×300 500×400
Weight (kg) 170 260 300 500
Dimensions L×W×H (mm) 500×700×1100 600×750×1100 700×900×1150 850×1050×1200
Standard Measuring System
  • Camera: SONY 1/3" Color CCD Camera
  • Lens Magnification: 0.7-4.5X (WD: 95mm)
  • Total Magnification: 30-230X
  • Object View: 7-1.1mm
  • Double Cross Line Generator
  • Data Resolution: 0.001mm
  • Z-axis Lifting Travel: 150mm (Auto Focus)
  • X,Y-axis Indication Error: ≤(3+L/200)μm (L = measured length in mm)
  • Lighting: LED surface and transmission light with adjustable brightness
  • Power: 220/110V AC, 50HZ, 30W
Warranty & Services
Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 4
  • 12-month comprehensive warranty with confidence guarantee
  • Coverage within 12 months from assembly/acceptance date (max 15 months from shipment)
  • Comprehensive phone and internet teaching with after-sale advisory service
  • Lifetime warranty services (cost-based for machine components)
  • Free technical service for machine failures caused by manufacturer (excluding travel and accommodation)
  • Lifetime after-sale advisory service beyond warranty period
  • Cost-based spare parts availability
  • Lifetime value-added technical services at preferential prices
Company Information
Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 5 Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 6
Certifications
Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 7
  • Software certified by national professional standard measurement organization
  • Machines eligible for HSR agency standard measurement certification
Packaging & Shipping
Manual 2D Coordinate Measuring Machine with 3um Accuracy and 220V 50HZ Power for Precision Measurement 8
Frequently Asked Questions
Why choose our measuring machines?
  • Over 10 years of specialized experience in measurement products
  • Professional R&D and after-sales teams
  • Located in Dongguan City, a world-renowned manufacturing hub
  • 12-month comprehensive after-sales service with 48-hour response for simple issues
What is your delivery time and packaging?
Standard delivery: 15-20 working days after deposit receipt
Customized machines: 25-35 working days
Professional packaging with machine packaging film internally and wooden box packaging with screw fixing externally to ensure safe arrival without damage.
Is on-site training available?
Yes, on-site training is available. Please coordinate specific timing with our sales representatives in advance.
